MESSKO® TRASY2 series
Indicator thermometer for distribution and power transformers
Your benefits at
a glance
|
Modular temperature measuring system for measuring oil and winding temperature
The MESSKO TRASY2 temperature measuring system is specially designed for measuring oil or winding temperature (thermal image) in medium and large-sized distribution transformers, power transformers, reactors, and similar applications.
The indicator thermometer is a stand-alone, energy-independent system which uses micro-switches for various switching functions. The measured value is captured by a liquid-filled temperature sensor and is then transmitted via a spiral spring which is linked with to an indicator axle. The thermometer has micro-switches with fully adjustable settings.
You can combine the following devices with the MESSKO TRASY2 series:
- Signal converter TT30 to convert the sensor signals into analog (for instance 4....20mA) or digital (RS485) process signals
- Measuring transducer Pt-MU to convert the signal of a Pt100 into a uniform signal proportional to the temperature
- Electronic indicator El100/160 for temperature indication in the control cabinet
- Digital indicator D1270 /1272 and/or
- Moving-coil indicator PQ96 /PQ144 for remote indication
- Multi-ballast transformer for adapting the current transformer output (CT) at the input of the indicator thermometer
 |
TRASY2 MT-ST160F |
|
TRASY2 MT-ST160F2 Indicator thermometer for measuring winding temperature (thermal image), with direct display |
