| Max. rated through-current single-phase: |
1,500 A |
| Max. rated through-current three-phase: |
600 A |
| Max. rated step voltage |
4,000 V |
| Max. rated switching capacity single-phase: |
4,280 kVA |
| Max. rated switching capacity three-phase: |
2,400 kVA |
| Max. voltage for operational equipment Um |
72.5 - 300 kV |
| Application: At the neutral point(three-phase) or as single-phase unit at any selectable winding position up to 1,500 A. |
| Operating positions without change-over selector |
18 max. |
| Operating positions with change-over selector |
35 max. |
